Model WSB-BP Wireline Set Bridge Plugs are compact, small OD and designed for easy drill out. These bridge plugs will set securely in all but the very highest tensile casing. A ratchet lock ring stores the setting force in the plug. The one piece packing element and metal back up rings combine for a superior seal. The case hardened, one piece slips virtually eliminate premature setting, yet can be easily drilled out.
- Can be set directly with Baker style wireline setting tools
- Easy for mill out
- Ratchet lock rings secure dynamic setting force
- One piece packing element and rocker action metal back up rings combine for a superior seal
- Shear studs are Baker style and connect directly to the Baker Adjuster Sub
- These bridge plugs can be run directly on Baker Setting Sleeves and Adjuster Subs
- Crossovers are not required.
Model HMB-BP Hydro-Mech Set Bridge Plugs are used for temporary or permanent isolation of oil, gas and water, such as, zone isolation, formation fracturing, and acidizing. These bridge plugs can be set by drop a ball and up lift, do not need any setting tools.
- Compact, easy running
- Can be released by right hand rotation in an emergency
- One piece packing element and rocker action metal back up rings combine for a superior seal
Model MSB-BP Mechanical Bridge Plugs are used to isolate zones for temporary or permanent abandonment. These drillable bridge plugs set securely in any hardness casing. A ratchet lock ring stores the setting force in the bridge plug. The one piece packing element and metal back up rings combine for a superior seal. The case hardened, one piece slips virtually eliminate premature setting, yet can be easily drilled out.
- Sets securely in any hardness casing, including premium grades
- Ratchet lock rings secure dynamic setting force
- One piece packing element and rocker action metal back up rings combine for a superior seal
- Compact, easy running
- Pressure balanced sleeve valve is opened and closed by tubing manipulation from the surface for better control
- Set with Model MST-BP Mechanical Setting Tool
- These bridge plugs can be set on any standard baker style mechanical setting tool
*Product sold as is
